Advantages of silicone system thermal conductive resin
Compared to non-silicone systems, there is a reduction in thermal resistance after various reliability tests.
Different products can be selected according to the film thickness
Thermal Resistance Reduction Through Thin Film Adjustment - G-OOO Series
When need to use thick film - choose CLG, SDP series
product name |
G-OOO series |
CLG series |
SDP series |
|
type |
One-component type |
Two-component type |
||
feature |
non-curing |
Curing type (condensation, additional) |
non-curing |
Curing type (additional) |
Utilize film |
filler |
Cured thermal grease
|
|
G-1000 |
G-789 |
GUV-300 |
type |
|
single component Hardening (Condensation/Deacetone) |
single component hardened (additional) |
single component Hardening (UV hardening) |
Exterior |
|
White |
White |
White |
Viscosity (Pa-s) |
Pa-s |
80 |
130 |
154 |
Standard curing conditions |
|
23℃×50%×7days |
125℃×90min |
6,000mJ(365nm)+25℃×24h |
Density after curing: 23℃ |
|
3.0 |
3.1 |
3 |
hardness |
Asker C |
40 |
10 |
Modulus 39 kPa.s |
Thermal conductivity |
W/m-k |
2.4 |
3.0 |
3.1 |
BLT |
μm |
50 |
25 |
- |
Thermal resistance |
mm2-K/W |
29 |
11 |
- |
breakdown voltage |
kV/mm |
14 |
14 |
- |
