product description

TEGO Dispers 750W Pigment wetting and dispersing aid. Wetting and stabilization of all pigments, good compatibility with colorants, hardly affecting stabilization.

  utility

project	project
Viscosity drop, organic pigments/carbon black	4
Color strength/gloss, organic pigments/carbon black	5
Viscosity drop, inorganic pigments/fillers	4
Color strength/gloss, inorganic pigments/fillers	5

0=Not applicable 5=Highly applicable

 suitability

project	Typical data
waterborne	Suitable for
solvent type	not applicable
Two-component type 100%	not applicable
radiation curing	not applicable
direct grinding	Suitable for
Resin-containing color paste	Suitable for
Resin-free color paste	Suitable for
Universal color paste	not applicable



  Solubility

project	Typical data
water	clear and soluble
Ethanol	clear and soluble
Tripropylene glycol diacrylate (TPGDA)	insoluble
Butyl acetate	insoluble
Petroleum solvent	insoluble



 Recommended dosage

Calculated according to the original material and inorganic pigments: 5-30%

Calculated on the basis of original materials and organic pigments: 20-70%

Calculated according to the original carbon black: 40-150%

Recommended dosage for co-grinding: 0.5-2.0%

Instructions for use

Add grinding before dispersing

This product should not be used as the sole wetting and dispersing additive when grinding carbon black pigments

A resistance test should be done before using unpainted stainless steel as a product for storage and transport

  recipe suggestion

Recommended dosage

Calculated according to the original material and inorganic pigments: 5-30%

Calculated on the basis of original materials and organic pigments: 20-70%

Calculated according to the original carbon black: 40-150%

Recommended dosage for co-grinding: 0.5-2.0%

  Instructions for use

Add grinding before dispersing

This product should not be used as the sole wetting and dispersing additive when grinding carbon black pigments

A resistance test should be done before using unpainted stainless steel as a product for storage and transport

recipe suggestion

1. Very good substitute for viscosity reduction: TEGO® Dispers 755 W

2. In order to achieve the best blackness of the lamp black, it is effective to use TEGO® Dispers 750 W with TEGO® Dispers 760 W (4:1 to 1:1 active).

3. In case air bubbles are generated during the pigment dispersion process, an efficient but also compatible defoamer can be used

agent concentrates (eg TEGO® Foamex 8050, TEGO® Foamex 810, TEGO® Foamex 830).

4. The addition of rheology modifiers (such as fumed silica) to inorganic pigment pastes has been shown to be beneficial.

5. The starting formula of color paste is available upon request.

chemical structure

Aqueous Copolymers with High Pigment Affinity Groups

  technical parameter

project

Typical data

Exterior

yellow transparent liquid

Active ingredient

Ca.40%

solvent

water

pH value (original state)

Ca. 6.5

suitability for food contact

Auxiliaries/monomers/solvents are listed in Tables A and B of Swiss Decree 817.023.21, Annex 6

storage security

When stored in the original unopened packaging, between +4 and +40°C, the shelf life of this product is at least 24 months from the date of manufacture.

  chemical structure

Aqueous Copolymers with High Pigment Affinity Groups

 technical parameter

project	Typical data
Exterior	yellow transparent liquid
Active ingredient	Ca.40%
solvent	water
pH value (original state)	Ca. 6.5



suitability for food contact

Auxiliaries/monomers/solvents are listed in Tables A and B of Swiss Decree 817.023.21, Annex 6

storage security

When stored in the original unopened packaging, between +4 and +40°C, the shelf life of this product is at least 24 months from the date of manufacture.
