Product Features
A hydrophilically modified aliphatic polyisocyanate based on isophorone diisocyanate (IPDI), Bayhydur® 401-60 PGDA can be used as a co-reactant for waterborne resins and as a curing agent for the preparation of chemical and weather resistant coatings
form of supply
About 60% propylene glycol diethyl ester solution
Characteristic data*
characteristic |
Numerical value |
Units of measurement |
method |
NCO content |
about 8.5 |
% |
M105-ISO 11909 |
Viscosity at23°C |
about 1100 |
mPa·s |
M014-ISO 3219/A.3 |
Color value (Hazen) |
≤60 |
|
M017-EN 1557 |
IPDI monomer content |
<0.30 |
% |
M106-ISO 10283 |
*This data is for reference only, and the product specifications that should be followed are subject to the final published information.
Other data**
characteristic |
Numerical value |
Units of measurement |
method |
equivalent |
about 494 |
|
|
Flash point |
about 84 |
°C |
DIN EN ISO 2719 |
Density at20°C |
about 1.11 |
g/cm3 |
DIN 51757 |
**This data is general information.
Solubility / dilution
In general, Bayhydur® 401-60 PGDA is dilutable with various polar to non-polar aliphatic solvents and is common in formulating paints. Dilutes to 20% solids with polar solvents. Diluents must be thoroughly tested for storage stability, especially when using gasoline-based diluents, which needs to be done with care and skill. Bayhydur® 401-60 PGDA is recommended for addition to gasoline soluble adhesives. Only use polyurethane grade solvents (less than 0.05% water). The solvent cannot contain reactive groups such as hydroxyl or amino groups.
compatibility
In general, Bayhydur® 401-60 PGDA can be mixed with various Desmodur® and Bayhydur® types such as Desmodur® N3300 or N3600, Bayhydur® 3100, XP 2655 or XP 2547.
However, compatibility must be tested in each case. At the same time, Bayhydur® 401-60 PGDA can be dispersed in various waterborne adhesives such as bayhydrol® types, such as Bayhydrol® A2470, A2646, A242, A2845 and U2755.
The overall formulation (solids content, co-solvent content, type of co-solvent) needs to be considered to achieve a stable and proper working formulation.
If you need technical support, please ask your supplier.
Features/Applications
Bayhydur® 401-60 PGDA is easy to emulsify into water-based paints or adhesives in the water phase and is mainly used as a co-crosslinking agent for Bayhydrol®-arranged water-based resins.
The coating properties of two-component polyurethane coatings, such as Bayhydur® XP 2655 or Bayhydur® XP 2487/1, are improved by the addition of Bayhydur® 401-60 PGDA to HDI-based Bayhydur crosslinkers.
A typical mixture of Bayhydur® 401-60 PGDA and the HDI-based Bayhydur crosslinker described above contains 5-30% Bayhydur® 401-60 PGDA in the total solids of the crosslinker.
The advantages of Bayhydur® 401-60 PGDA are as follows:
final performance, e.g.
• Increased surface hardness;
• Increased chemical and solvent resistance.
application performance, such as
• Significantly longer pot life, even at high processing temperatures;
• Faster drying;
• Improved robustness, including increased bubble-free layer thickness.
