Surface Modifiers

3M FC-4430 Fluorocarbon Surfactant

Product introduction
3M FC-4430 is a water-soluble ethoxylated non-ionic fluorocarbon surfactant with 100% active substance.

physical properties

Exterior	The khaki wax-like substance melts into a liquid when heated to 40°C. Please completely melt and stir well before use.
Structural formula	RfCH2CH2O（CH2CH2O）nH Rf=F（CF2CF2）m n=0~25 m=1~9
molecular weight	~950
Component	100%氟碳表面活性剂
Density@25℃	1.35
Solubility	Soluble in water, methanol, isopropanol, acetone, ethyl acetate, toluene, tetrahydrofuran and chloroform (>2%), insoluble in n-heptane
Surface tension (deionized water), 25°C	29dyn/cm at 0.001% active ingredient, 24dyn/cm at 0.01% active ingredient, 23dyn/cm at 0.1% active ingredient
other	Waxy solid at low temperature, liquid when heated to 40°C, flash point >93°C, non-flammable/non-dangerous, PH: 6~8, best application PH range: 2~12

Application Features

Emulsifying properties (halogenated raw materials): Effective
Wetting properties: highly effective
Washing performance: ineffective
Dispersion performance (halogenated raw materials): effective
Foaming performance: effective
Compatibility: Can be widely used in acid/alkali and soft/hard water systems

application
Metal/Electronic: It can improve the etching effect, and can be used as a plating aid and an oxidation inhibitor for zinc batteries; in the flux based on rosin, a fluorosurfactant is added to form a high-efficiency flux (rosin + FC-4430 + glycerin). + isopropyl alcohol), immerse the electronic printed circuit board soldering parts to be soldered in the flux for several minutes. After drying, it can be automatically welded, with good foaming, uniform tinning, full solder joints, and less flux residue. It can improve the strength of the coating and eliminate the common defects such as pinholes and cracks in the electroplating process.

Product packaging
8 lbs or 50 lbs/drum
