560 γ-(2,3-glycidoxy)propyltrimethoxysilane Silane coupling agent





 Product Description

Structural formula

molecular formula

C9H20O5Si

molecular weight

236

CAS NO

2530-83-8

Chemical Name

γ-(2,3-glycidoxy)propyltrimethoxysilane





  characteristic
   560 It is an organosilane with an epoxy group and a hydrolyzable inorganic methoxysilyl bifunctional group. This bifunctional structure endows 560 with special properties: it can organically bond inorganic materials (such as glass, metals, fillers) and organic polymers (such as thermoplastics, thermosets, or elastomers) together to play a role in Promotes adhesion, action of crosslinkers and/or surface modifiers.
It is a colorless, low-viscosity liquid with a slight rosin odor, soluble in alcohols, ketones, chain hydrocarbons or aromatic hydrocarbons.

 Physical and chemical data

nature

Numerical value

Exterior

Colorless transparent liquid

purity

98%

Density@25℃

1.07g/ml

Boiling point 760mmHg

290℃

closed cup flash point

110℃

Refractive index@25℃

1.428

Note: The above data are for reference only and cannot be formulated as technical specifications


  nature of reaction

       560 In the presence of water, the methoxy group will be hydrolyzed to form a reactive silanol group, which can form bonds with the surface of various inorganic substrates.
The hydrolysis of 560 can be catalyzed by organic acids such as acetic acid.
Suitable inorganic materials like: glass, fiberglass, quartz, cristobalite and metals.
Resins that can be used for -560 include, epoxy, phenolic, polyurethane, PAVC, acrylic and polysulfide rubber.

  Applications
560 is an important component in many industrial products, such as:
1. Glass fiber/electronic cloth composite material: as a whole or a sizing component
2. Casting resin: as an additive for polyurethane resin
3. Sealants and adhesives: as primers or additives
4. Inorganic filled compounds: pretreatment of fillers or pigments or as additives to polymers
5. Paints and coatings: as a primer or additive to improve adhesion to substrates, especially glass and metals
6. Improve the service life of aminosilane in polyurethane

The 560 can also bring important performance to end products, including:
Improve mechanical properties such as flexural strength, tensile strength, impact strength and modulus of elastomers
Improves moisture and corrosion resistance
Improve electrical properties such as dielectric constant, volume resistivity

Improve processing performance such as:
Improve filler dispersion
Rheological behavior: reduced viscosity, Newtonian behavior
Increase filler loading
not yellowed

Product safety, handling and storage
Before using this product, you should carefully read the latest product safety technical information and toxicity data of this product, as well as the correct storage, transportation and use information of this product.
After the container is opened, it should be sealed to prevent the entry of water vapor and cause hydrolysis.
The expiration date of the product is indicated on the label. Exceeding this time does not mean that the product can no longer be used, and it can still be used after the performance test is confirmed to be qualified.
