CERAFAK 103
Dispersion of ethylene acrylic acid copolymer wax for solvent-borne effect coating systems; improves orientation of effect pigments, reduces
Settling in the tank.
chemical components
Dispersion of ethylene vinyl acetate copolymer wax.
Typical materialized data
The data given on this data sheet are only typical values, not the technical specifications of the product.
Non-volatile matter | 6 % |
Carrier | 7/8/1 xylene/butyl acetate/n-butanol |
Melting point (wax content) | 110 °C |
Fineness | 15 μm |
Viscosity (23 °C) |
10 mPa·s |
storage and transportation
This product is temperature sensitive. Store and transport below 35°C and mix well before use.
special reminder
Graining test method: Disperse the wax additive at 4 m/s for 5 minutes, then add 20% butyl acetate, keep stirring at 4 m/s for 2 minutes, use a 100 um film applicator
Scraper on a glass plate. The coating should be clear and free of particles during drying.
Fineness test method: scraper fineness meter, ISO1524. Disperse the wax additive at 4 m/s for 5 minutes, test with a 50um scraper fineness meter, fineness: 15um.
Application field
paint industry
Features and advantages: The additive can improve the directional arrangement of effect pigments such as aluminum powder and pearlescent powder, and improve the effect of different light and different colors; reduce short-wave defects (spotting, Bernard vortex), and improve the performance of the next overcoat varnish. Leveling; prevent settling in the tank.
Recommended use
CERAFAK 103 is recommended for solvent-borne basecoats and single-coat automotive metallic topcoats.
Recommended dosage
50% additive dosage (as purchased) is based on solid resin.
The above recommended dosage is for reference, and the optimal dosage needs to be determined through a series of tests
Joining method and processing guidance
The wax additive was uniformly dispersed at 4 m/s, and the resin solution was added under stirring. In the system containing CAB, the CAB solution should be uniformly dispersed with the resin solution at high speed (> 5 m/s), and then the stirred wax slurry should be added. Pigment paste and solvent should be added with stirring.
